Description

Description:

Basic

information

Brand:SCY

Models:LH18108

Model:1/18

Speed:28km/h

Color:Red/Green

Power system

ESC/receiver:25A 2S integrated control splashproof

Motor:RC380 high-speed carbon brush strong magnet magnetic protection + heat sink

Servo:5-wire, 17g

Transmitter

Frequency:2.4 GHz

Battery: 3XAA batterynot included

Transmitter Size:12.6*8.2*18.5 CM

Transmitter weight:190g

Remote control category:Full-proportional synchronous control system gun control

Battery:

7.4V 1500mAH lithium-ion battery T plug

others

Charge time:3-3.5 hours USB balance charging

Using time:35-40 minutes continuous full speed running

Control distance:≥80m

Protection function:Charging protection, stuck protection, high temperature protection, low voltage protection.

Headlight configuration:LED headlights, white roof lights.

Differential structure:Metal differential planetary gear.

Materials:Hardware; Electronics; Plastic

Functions:Adopting simulation structure design, it has the control feeling of a real car, realizing full-proportional stepless speed change, high-speed driving, sudden acceleration, deceleration, braking, reversing, left turn, right turn.

Dimension

Car Size:27.5*19*10.3 CM

Wheelbase: 165mm

Wheelbase: 155mm

Wheel diameter: 67mm

Package size:29.5*15.5*22 CM

Vehicle weight:850g

Packaging weight:1510g





Features:

1.High-Speed Motor: Equipped with an RC380 high-speed carbon brush motor with strong magnets and heat dissipation for optimal performance.

2.Construction: Built from high-quality metal, electronics, and plastic to withstand rough terrain.

3.4WD System: Offers superior handling with all-wheel drive, suitable for various surfaces including sand, mud, grass, and flat ground.

4.Advanced Suspension: Features front and rear upright spring shocks and dual-arm independent suspension for smooth rides.

5.Comprehensive Protection: Includes overcharge , high temperature, and low voltage protection for safe operation.

6.LED Lighting: Comes with LED headlights and roof lights with three modes: steady, slow flash, and fast flash.

7.Long Battery Life: Enjoy 35-40 minutes of continuous play with the included 7.4V 1500mAh Li-ion battery. USB charger included for convenience.



Notes:

1.Charging protection: constant current and constant voltage balanced charging, protection against battery overcharge and overcurrent.

2.Motor anti-stuck protection: when overloaded, the motor stops working.

3.High temperature protection: when the working temperature is higher than the set temperature, the drive control circuit stops working, and resumes working after the temperature drops to a safe value.

4.Electric low voltage power-off function, the battery is lower than about 6.3-6.4V, and the power is automatically cut off to prevent the battery from being damaged by over-discharge.



Package included:

1 X vehicle

1 X Transmitter

1 X Manual

1 X Battery

1 X USB Charger
